wet magnetic separator

Usage and application :

The Low Intensity Wet Drum Magnetic Separator is mainly used for iron ore beneficiation , remove the iron tramp as the impurity form the industrial materials by wet processing

CTB wet semi-countercurrent magnetic separator is suitable for cleaning and cleaning of strong magnetic materials with particle size below 0.5mm for wet separation of ores, especially for the selection of minerals with particle size of 0.15~0mm. Or remove the strong magnetic minerals mixed from non-magnetic minerals.

Working principle:

When the ore pulp flow into the magnetic field, the strong magnetic minerals are adsorbed on the surface of the drum. The weak magnetic and non-magnetic minerals are cast off and discharged, while the strong magnetic minerals on the surface of the drum rotate with the drum and will be brought out of magnetic field to complete the sorting operation.

Features:

1. Advanced magnetic circuit design, deep magnetic ef­fective depth and high recovery.

2. Simple and compact structure, strong magnetic force.

3. Easy to maintain, easy installation, reliable performance.

4. Stable and reliable driving device, no malfunction or breakdown for a long time.

Technical specifications:
